Power output amplifier DIN-assembled

Output MOSFET 400W. Only 0.1 watt power consumption in standby mode. Modular unit for rail mounting according to DIN-EN 60715 TH35. 1 module = 18mm wide, 58mm deep.
NOTE: Contactors for increasing the switch capacity shall not be connected in series to this kind of device. The output enhancer LUD12-230V can be connected to EUD12Z, EUD12D and SUD12/1-10V.. This results in an increase in the switch capacity on one wire with up to 400, 350 or 300W according to the drawing below, depending on the ventilation conditions. Alternatively with several lighting wires up to 400W/output enhancers. Only with extra lights for low-energy lamps (ESL) as 100W per light may not be exceeded.
Both switches’ functions can be done simultaneously for added output. Automatic detection of the load “Output enhancing on several lighting wires".
Control voltage 230V. Automatic electronic overload and temperature protection. When “Output enhancing on several lighting wires", the type of load that can be coupled in to the output enhancer LUD12-230V can differ from the one that the pressure dimmer controls. In this way it is possible to mix L- and C-loads.
