Schneider Electric
ComPacT NSX100 / 160/250 circuit breaker
NSX100F 36kA AC 3P 100A C10F3
Artikelnummer: Lev. artikelnr:
3184226
C10F3
för att se saldo och pris
ComPacT NSX100 / 160/250 circuit breaker
- Article number: 3184226
- Suppl. article no: C10F3
- Ean no: 3606481999320
- Material class QO211B
Teknisk data
- Packagin Size: 1 PCS/7 PCS/56 PCS
- Type: C10F3
- Rated permanent current Iu: 100 A
- Rated short-circuit breaking capacity Icu at 400 V, 50 Hz: 36 kA
- Number of poles: 3
- Integrated earth fault protection: No
- Type of electrical connection of main circuit: Screw connection
- Device construction: Built-in device fixed built-in technique
- Suitable for DIN rail (top hat rail) mounting: No
- Number of auxiliary contacts as normally closed contact: 0
- Number of auxiliary contacts as normally open contact: 0
- Number of auxiliary contacts as change-over contact: 0
- With switched-off indicator: Yes
- Position of connection for main current circuit: Front side
- Type of control element: Wing knob
- Motor drive integrated: No
- Motor drive optional: Yes
- Degree of protection (IP): IP40
- Complete device with protection unit: No
- DIN rail (top hat rail) mounting optional: Yes
- Rated voltage: 690 V
- REACH Date: 2022-07-20
- REACH contains candidate substances: Bly
- REACH Information obligation: Yes
