Eaton
Earth fault breaker Xpole series PFIM, 4-pole, surge-proof 250A type A
RCCB, 25A, 4P, 30MA, TYPE A PFIM-25/4/003-A
Article number: Suppl. article no:
2162229
Y7-235435
to see price and stock
Suitable for outdoor use at -25ºC. Surge-proof version (250A, 8/20µs) for general use. Type PFIM-...-A. Pulse current sensitive, for use where pulsing DC fault currents may occur, surge-proof, non-selective, non-short term delayed. Type PFIM-...-G/A. Short-term delayed earth fault breaker (min 10ms) for personal protection with power-safe version (3000A). Senses pulsing DC. Type PFIM-...- U. Selective earth fault breaker for frequency convertor operation, surge-proof up to 5000A.
Connection of neutral to right.
Connection of neutral to right.
- Article number: 2162229
- Suppl. article no: Y7-235435
- Ean no: 4015082354350
- Material class QL4700
Technical data
- Packagin Size: 1 ST/30 ST
- Type: PFIM-25/4/003-A
- Leakage current type: A
- Number of poles: 4
- Rated voltage: 400 V
- Voltage type: AC
- Rated current: 25 A
- Rated fault current: 0.03 A
- Built-in depth: 70.5 mm
- Width in number of modular spacings: 4
- Surge current capacity: 0.25 kA
- Selective protection: No
- Short-circuit breaking capacity (Icw): 10 kA
- Frequency: 50 Hz
- Short-time delayed tripping: No
- Degree of protection (IP): IP20
- Additional equipment possible: Yes
- Connectable conductor cross section solid-core: 1.5-35 mm²
- Connectable conductor cross section multi-wired: 1.5-16 mm²
- Mounting method: DIN rail
- Pollution degree: 2
- Rated impulse withstand voltage Uimp: 4 kV
- Rated insulation voltage Ui: 440 V
- Ambient temperature during operating: -25-55 °C
- With interlocking device: Yes
- Explosion-proof: No
- REACH Date: 2023-08-31
- REACH contains candidate substances: Bly
- REACH Information obligation: Yes
