Osram
LED lamp NAV LED
LED NAV 70 35W 740 E27 4058080000000
Article number: Suppl. article no:
8296741
4058075453746
to see price and stock
OSRAM NAV LED with E40 base replaces traditional high-pressure sodium in existing installations with conventional drives, compensation capacitor and lighter. Quick, easy change without switching. Similar light distribution as traditional high-pressure sodium thanks to the radiant scattering angle. Up to 52% energy savings. Compatible with drives that have night lowering. Low maintenance costs due to long life. Common application areas are streets, area lighting, pedestrian areas and parks.
- Article number: 8296741
- Suppl. article no: 4058075453746
- Ean no: 4058075453746
- Material class QV7540
Technical data
- Packagin Size: 1 ST/10 ST
- Energy label: D
- Socket: E27
- Luminous flux: 6000 lm
- Colour temperature: 4000 K
- Lamp power: 35 W
- Length: 190 mm
- Type of glass/cover: Clear
- Colour: White
- Nominal voltage: 70-110 V
- Beam angle: 360 °
- Lamp shape: Capsule/stick
- Dimmable: No
- Average nominal lifetime: 50000 h
- Housing colour: Other
- Diameter: 70 mm
- Rated luminous flux according to IEC 62612: 6000 lm
- Voltage type: AC
- Colour rendering index CRI: 70-79
- Colour of light according to EN 12464-1: Neutral white 3300-5300 K
- Degree of protection (IP): IP40
- Power factor: 0.7
- Remote operation possible: No
- Photobiological safety according to EN 62471: RG1
- Colour consistency (McAdam ellipse): SDCM6
- Filament lamp: No
- Lamp designation: Other
- Lamp efficacy: 171 lm/W
- With remote control: No
- Min. number of switching cycles: 100000
- Weighted energy consumption in 1000 hours: 39 kWh
- Compatible with Amazon Alexa: No
- Compatible with Apple HomeKit: No
- Compatible with Google Assistant: No
- IFTTT support available: No
- Nominal current: 790 mA
- Energy efficiency class according to EU regulation 2019/2015: D
- REACH Date: 2022-06-01
- REACH Information obligation: No
