Driver kit sense
SENSE DRIVERKIT 700MA DALI
Article number: Suppl. article no:
7981373
820083
to see price and stock
Driver including cabling for LED panel Sense. SG's new junction boxes have several connection options, both for cable and flex pipe. With integrated Linect coupling enables the use of quick coupling systems from Wago, Ensto and Wieland. All connections can be made without tools. The models with Linect offer a solution with full flexibility, something that previously had to be customized and procured with long delivery times as a result.
- Article number: 7981373
- Suppl. article no: 820083
- Ean no: 7021988200834
- Material class QQ3830
Technical data
- Packagin Size: 1 ST/20 ST/20 ST/480 ST
- Design: Dali, Linect
- Output current: 700 mA
- Output voltage: 3-48 V
- Output power: 0-32 W
- Degree of protection (IP): IP20
- Suitable for constant voltage: No
- Suitable for constant current: Yes
- Suitable for DC-voltage (primary side): Yes
- Suitable for outdoor use: No
- Height: 21 mm
- Length: 103 mm
- Width: 67 mm
- Housing: Plastic housing
- Diameter: 0 mm
- Model: Static
- Protection class according to IEC 61140: II
- Dimmable: Yes
- Dimming DALI: Yes
- Dimming 0-10 V: No
- Dimming 1-10 V: No
- Dimming DMX: No
- Dimming DSI: No
- Dimming LineSwitch: No
- Dimming RF: No
- Dimming Zigbee: No
- Dimming potentiometer (integrated): No
- Dimming programmable: No
- Dimming manufacturer's proprietary system: No
- Dimming Touch and Dim: No
- Dimming with push-button: No
- Dimming Sine Wave Reduction: No
- Dimming mains voltage modulation: No
- Dimming phase cut-off (trailing edge): No
- Dimming phase cut-on (leading edge): No
- Compatible with Amazon Alexa: No
- Compatible with Apple HomeKit: No
- Compatible with Google Assistant: No
- IFTTT support available: No
- Operation by Bluetooth: No
- Compatible with Casambi: No
- REACH Date: 2024-08-23
- REACH Information obligation: No
- Dimming GPRS: No
