Schneider Electric
Downlight Exxact
Down light white 25gr 3000K
Article number: Suppl. article no:
7475682
IMT47260
to see price and stock
The Schneider Electric LED downlight is designed for general lighting in homes or simpler commercial buildings. Functionally tested and works optimally with all of Schneider Electric's dimmers.
- Article number: 7475682
- Suppl. article no: IMT47260
- Ean no: 3606482153288
- Material class QT4580
Technical data
- Packagin Size: 1 PCS/24 PCS/576 PCS
- Max. system power: 8 W
- Rated luminous flux according to IEC 62722-2- 1: 610 lm
- Colour temperature: 3000 K
- Housing colour: White
- Surface brushed: No
- Beam angle: 21-40° - Medium beam
- Dimming DALI: No
- Dimming DALI-2: No
- Outer diameter: 92 mm
- Built-in diameter: 83 mm
- Height/depth: 45 mm
- Lamp type: LED exchangeable
- Adjustability: Rotatable
- With light source: Yes
- Colour of light: White
- With control gear: Yes
- Type of control gear: LED operating device current-controlled
- Luminous intensity: 1120 cd
- Reflector: High-gloss
- Housing material: Aluminium
- Suitable for workplace according to EN 12464-1: No
- Number of poles: 2
- Dimming phase cut-off (trailing edge): Yes
- Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24: No
- Width: 92 mm
- Dimming with push-button: No
- Dimming Sine Wave Reduction: No
- Dimming mains voltage modulation: No
- Dimming 0-10 V: No
- Dimming 1-10 V: No
- Dimming DMX: No
- Dimming DSI: No
- Dimming LineSwitch: No
- Dimming RF: No
- Dimming Zigbee: No
- Dimming potentiometer (integrated): No
- Dimming programmable: No
- Dimming manufacturer's proprietary system: No
- Rated ambient temperature according to IEC 62722-2-1: -20-45 °C
- Total harmonic distortion (THD): 0.25 %
- Power factor: 0.9
- Photobiological safety according to EN 62471: RG1
- Dimming phase cut-on (leading edge): Yes
- Filament test according to IEC 60695-2-11: 650 °C - 30 s
- Material cover: Plastic, transparent
- Degree of protection (IP): IP20
- Dimmable: Yes
- Lamp holder: Other
- Conductor cross section: 0.75 mm²
- Light distribution: Symmetric
- Protection class according to IEC 61140: II
- Light distributor: Reflector
- Light outlet: Direct
- Luminaire efficacy: 75 lm/W
- Suitable for number of light sources: 1
- Colour rendering index CRI: 90-100
- Suitable for built-in mounting: Yes
- Suitable for clamp-mounting: No
- Suitable for lamp power: 8 W
- Suitable for low voltage cable system: No
- Suitable for pedestal/floor mounting: No
- Suitable for suspended mounting: No
- Suitable for light-track mounting: No
- Suitable for traverse mounting: No
- Suitable for wall mounting: No
- Suitable for surface mounting: No
- Length: 92 mm
- With light sensor: No
- With movement sensor: No
- Nominal voltage: 220-240 V
- Voltage type: AC
- Rated lifetime L70/B50 at 25 °C: 100000 h
- Suitable for ceiling mounting: Yes
- Degree of protection (NEMA): Other
- Impact strength: IK02
- Dimming Touch and Dim: No
- Type of wiring: Suitable for loop-through wiring
- Connectable conductor cross section: 0.75-2.5 mm²
- Surface protection: Powder coating
- Colour consistency (McAdam ellipse): SDCM3
- Covering of the luminaire with thermally insulating material possible: Yes
- Lumen maintenance at median useful life of 100,000 h at 25 °C ambient (tq): 80 %
- Lumen maintenance at median useful life of 35,000 h at 25 °C ambient (tq): 93 %
- Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq): 91 %
- Failure rate at median useful life of 100,000 h at 25 °C ambient (tq): 10 %
- Failure rate at median useful life of 35,000 h at 25 °C ambient (tq): 1 %
- Failure rate at median useful life of 50,000 h at 25 °C ambient (tq): 3 %
- Flickering value Pst LM: 0.1
- Beam angle adjustable: No
- Colour of light adjustable: No
- Compatible with Amazon Alexa: No
- Compatible with Apple HomeKit: No
- Compatible with Google Assistant: No
- Constant light output (CLO): No
- Luminous flux adjustable: Continuously variable
- Max. number of luminaires per miniature circuit breaker B16 (MCB): 108
- Max. number of luminaires per miniature circuit breaker C16 (MCB): 180
- IFTTT support available: No
- Stroboscope effect value SVM: 0.1
- Unified Glare Ratio (UGR): 19
- Exchangeable control gear: Yes
- Connection type: Push-in clamp
- Luminous flux: 590-630 lm
- Built-in width: 83 mm
- Built-in length: 83 mm
- REACH Date: 2023-03-20
- Built-in height/depth: 43 mm
- REACH contains candidate substances: Bly
- REACH Information obligation: Yes
- Emergency power supply integrated: No
