Hide-a-lite
Downlight Core Smart, Hide-a-Lite
DOWNL CORE SMART 15° WHI 2700K CORE SMART
Article number: Suppl. article no:
7470537
7470537
to see price and stock
Small, high-quality accent luminaire for indoor use, with integrated quick-connect terminal block, 4x0.2-0.75, for simplified and smart series connection that eliminates hassle with external joints, minimizes sources of error and simplifies troubleshooting. The recessed light point makes the luminaire well dimmed. A good alternative where a spreading angle of 15 ° is desired Beautiful as decorative lighting recessed in window niches and furniture.
Available in 15, 45 ° and 120 °.
Available in 15, 45 ° and 120 °.
- Article number: 7470537
- Suppl. article no: 7470537
- Ean no: 7392971134079
- Material class QT4320
Technical data
- Packagin Size: 1 ST/100 ST/100 ST
- Design: 15°
- Max. system power: 1.3 W
- Rated luminous flux according to IEC 62722-2- 1: 30 lm
- Colour temperature: 2700 K
- Housing colour: White
- Surface brushed: No
- Beam angle: 11-20° - Narrow beam
- Dimming DALI: No
- Outer diameter: 30 mm
- Built-in diameter: 25 mm
- Built-in height: 35 mm
- Height/depth: 37 mm
- Lamp type: LED not exchangeable
- Adjustability: Not adjustable
- With light source: Yes
- Colour of light: White
- With control gear: No
- Type of control gear: LED operating device current-controlled
- Luminous intensity: 160 cd
- Reflector: None
- Housing material: Aluminium
- Suitable for workplace according to EN 12464-1: No
- Number of poles: 2
- Dimming phase cut-off (trailing edge): No
- Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24: No
- Dimming with push-button: No
- Dimming Sine Wave Reduction: No
- Dimming mains voltage modulation: No
- Dimming 0-10 V: No
- Dimming 1-10 V: No
- Dimming DMX: No
- Dimming DSI: No
- Dimming LineSwitch: No
- Dimming RF: No
- Dimming Zigbee: No
- Dimming potentiometer (integrated): No
- Dimming programmable: No
- Dimming manufacturer's proprietary system: No
- Rated ambient temperature according to IEC 62722-2-1: -20-45 °C
- Photobiological safety according to EN 62471: Other
- Dimming phase cut-on (leading edge): No
- Filament test according to IEC 60695-2-11: 650 °C - 30 s
- Material cover: None
- Degree of protection (IP): IP44
- Dimmable: Yes
- Lamp holder: None
- Conductor cross section: 0.75 mm²
- Light distribution: Symmetric
- Protection class according to IEC 61140: III
- Light distributor: None
- Light outlet: Direct
- Luminaire efficacy: 25 lm/W
- Suitable for number of light sources: 1
- Colour rendering index CRI: 90-100
- Suitable for built-in mounting: Yes
- Suitable for clamp-mounting: No
- Suitable for low voltage cable system: No
- Suitable for pedestal/floor mounting: No
- Suitable for suspended mounting: No
- Suitable for light-track mounting: No
- Suitable for traverse mounting: No
- Suitable for wall mounting: No
- Suitable for surface mounting: No
- With light sensor: No
- With movement sensor: No
- Voltage type: DC
- Rated lifetime L70/B50 at 25 °C: 90000 h
- Suitable for ceiling mounting: Yes
- Impact strength: Other
- Dimming Touch and Dim: No
- Type of wiring: Ending
- Connectable conductor cross section: 0.2-0.75 mm²
- Surface protection: Powder coating
- Colour consistency (McAdam ellipse): SDCM3
- Covering of the luminaire with thermally insulating material possible: No
- Beam angle adjustable: No
- Colour of light adjustable: No
- Connection type: Push-in clamp
- Luminous flux: 30 lm
- LED nominal current at constant current: 350 mA
- REACH Date: 2022-06-01
- Dimming GPRS: No
- Energy efficiency class of the built-in lamp: A++, A+, A (LED)
- REACH Information obligation: No
- Emergency power supply integrated: No
- Dimming depending on control gear: Yes
