Emergency lighting fixture Too Pac LED - EXIT SIGN
https://www.youtube.com/watch?v=/external-assets/JPEGlarge800_800/86/66/ProductImage35938666.jpg
https://www.youtube.com/watch?v=/external-assets/JPEGlarge800_800/86/67/ProductImage35938667.jpg
Kamic

Emergency lighting fixture Too Pac LED

EXIT SIGN
Article number:
7345497
Suppl. article no:
2X190101ESA6





 to see price and stock
Produkten är miljöbedömd av SundaHusProdukten är bedömd hos Byggvarubedömningen med totalbedömningen Undviks.
The Too Pac LED is constructed in polycarbonate with a swivel bracket that makes it easy to mount on the wall, ceiling or slant indoors. A suitable choice for most environments such as schools, shops, offices etc. The luminaire is equipped with self-test and efficient Li-ion battery for up to three hours of operating time in the event of a power failure. Energy efficient with a consumption of only 1W in normal operation. The reading distance is 30 meters and practical "snap-in pictogram signs" are included in the delivery. 1 left / right arrow and 1 down / down arrow. Protection class: IP20, class II. Charging time: 24 h. Ambient temperature during operation: + 50– +40 C. Delivered in two packs.
  • Article number:
    7345497
  • Suppl. article no:
    2X190101ESA6
  • Ean no:
    7331942013586
  • Material class
    QT2920
Technical data
  • Type: 2X190101ESA6
  • Recognition distance: 30 m
  • Width: 308 mm
  • Height/depth: 43 mm
  • Length: 235 mm
  • Type of indicator: Single/double-sided
  • Housing colour: White
  • Max. system power: 1 W
  • With pictogram: Yes
  • Housing material: Plastic
  • Lamp type: LED not exchangeable
  • Degree of protection (IP): IP20
  • Protection class according to IEC 61140: II
  • Impact strength: IK05
  • Mounting method: Wall surface mounting/ceiling surface mounting
  • Number of poles: 3
  • Battery technology: Lithium-ion
  • Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24: No
  • Function: Escape route signage
  • Material cover: Plastic, transparent
  • Lamp holder: None
  • Conductor cross section: 2.5 mm²
  • Light distributor: Diffuser lens/optic/panel
  • Suitable for labelling type: Acrylic plate
  • With light source: Yes
  • Nominal voltage: 220-240 V
  • Nominal operation time: 3 h
  • Rated lifetime L70/B50 at 25 °C: 50000 h
  • Rated ambient temperature according to IEC 62722-2-1: 5-40 °C
  • Voltage type: AC
  • Type of wiring: Ending
  • Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq): 80 %
  • Failure rate at median useful life of 50,000 h at 25 °C ambient (tq): 10 %
  • Constant light output (CLO): Yes
  • With remote control: No
  • Exchangeable control gear: No
  • Energy efficiency class of the light source according to EU regulation 2019/2015: Not required
  • Suitable for continuous circuit: Yes
  • Suitable for standby switching: No
  • Connection type: Plug-in connection
  • Type of lithium-ion battery: Lithium iron phosphate (LiFePO4)
  • REACH Date: 2021-03-18
  • REACH Information obligation: No
  • Power supply system: Peripheral (individual battery)
  • Monitoring equipment: Automatic self test
