Butterfly valve AVI 1483 EPDM Wafer, a-collection
DN200 BFV VALVE 1483EPDM WAFER F07-F10 PN10/ANSI150 SHAF DVGW
Article number: Suppl. article no:
4017369
309A200E
to see price and stock
Soft-sealing butterfly valve AVI 1483 with replaceable EPDM lining, Wafer model for tightening between flanges. High neck for insulation and lockable handle. ISO 5211 top flange for direct mounting of gear or actuator
- Article number: 4017369
- Suppl. article no: 309A200E
- Ean no: 7340080786245
- Replaces art.nbr: 4659499
- Material class PIH020
- This is an alternative to item 4565598
Technical data
- Nominal diameter: DN 200
- Material valve butterfly: Stainless steel
- Sealing: Ethylene-propylene diene monomer rubber (EPDM)
- Surface protection: Coated
- Valve butterfly lined: Yes
- Medium temperature (continuous): -15-110 °C
- Article compression class: PN 10
- Construction length: 60 mm
- Material quality: Cast iron EN-GJS-400-15 (GGG 40)
- Housing material: Cast iron
- Connections: Wafer type
- Design: Free axle
- Valve housing: EN-JS-1025
- Damper type: 1.4408
