Ball Valve AVI 1351, a-collection
BALL VALVE 3P BW DN25 26/30MM AVI 1351 TFM1600 ISO 5211 PN63
Article number:
5493201
to see price and stock
Ball valve, 3-section, in stainless steel, short metric welded end. Full through-flow, floating homogeneous ball, and antistatic spindle, TFM1600 ball seat sealing and locking handle. Assembly flange ISO 5211 for direct assembly of control device.CE/PED 97/23/EC Category III, Module H Valves DN32-DN100 are marked CE0035 ISO 15848-1.
- Article number: 5493201
- Ean no: 7340080781202
- Material class PIF010
Technical data
- Packagin Size: 1 ST/18 ST
- Medium temperature (continuous): -20-200 °C
- Nominal diameter connection 1: DN 25
- Article compression class: PN 63
- Nominal diameter connection 2: DN 25
- Outer pipe diameter connection 1: 30 mm
- Outer pipe diameter connection 2: 30 mm
- Construction length: 85 mm
