Saniflo
Pumping Station Sanidouche+, Saniflo
SANIDOUCHE + FOR SHOWER. WASHBASIN
Article number: Suppl. article no:
5885405
5885405
to see price and stock
- Article number: 5885405
- Suppl. article no: 5885405
- Ean no: 3308815074030
- Replaces art.nbr: 5886509
- Material class PHM140
Technical data
- Packagin Size: 1 ST/11 ST/44 ST
- Degree of protection (IP): IP44
- Nominal current: 1.3 A
- Depth: 166 mm
- Nominal diameter connection outlet side: 1 inch (25)
- Width: 308 mm
- Connection inlet side: Other
- Motor power input (P1) per motor: 250 W
- Number of pumps: 1
- Electrical connection: Cable
- Height: 146 mm
- With cutting system: No
- Suitable for faeces: No
- Material pump casing: Polypropylene (PP)
- Set-up behind toilet bowl: No
- Outer pipe diameter connection inlet side: 40 mm
- Outer pipe diameter connection outlet side: 28 mm
- With de-aeration: Yes
- Max. static height: 4 m
- Nominal diameter connection inlet side: 1 1/2 inch (40)
- With alarm function: No
- Alarm output: No
- Number of inlet ports: 2
- Suitable for outdoor installation: No
- Rated voltage: 230 V
- Volume flow rate (BEP): 4.2 m³/h
