Expansion vessel 100-600, a-collection
200/1.5 200LIT EXPANS VESSEL WO ACCESSOR/ MAX. 6BAR A-FLEX
Article number: Suppl. article no:
5534934
16389
to see price and stock
Cooling water tank, 100 to 600 litres, max. work pressure 6 bar.
- Article number: 5534934
- Suppl. article no: 16389
- Ean no: 7333123014559
- Material class PEH010
Technical data
- Packagin Size: 1 PCS/8 PCS
- Volume: 200 l
- Connection: External thread cylindrical BSPP-G (ISO 228-1)
- Nominal diameter expansion connection: 1 inch (25)
- Outer pipe diameter, expansion connection: 25 mm
- Height: 1296 mm
- Diameter: 484 mm
- Pre-pressure: 1.5 bar
- With fixed wall support: No
- With exchangeable membrane: No
- Colour: Red
- Suitable for central heating: Yes
- Suitable for cooling: Yes
- Suitable for tap water: No
- Material membrane/bladder: Ethylene-propylene diene monomer rubber (EPDM)
- Max. operating pressure: 6 bar
- Max. glycol mixture: 50 %
- With drain: No
- With legs: Yes
- With pressure gauge: No
- With safety valve: No
- With vessel manifold: No
- Medium temperature (continuous): -10-70 °C
- Opening pressure safety valve: 6 bar
- Weight: 38.1 kg
- Type: A-FLEX
