Actuator SKD60, Siemens
VALVEACTUATOR SKD60 0-10V 24V LIFTING HEIGHT 20 MM
Article number: Suppl. article no:
5353638
BPZ:SKD60
to see price and stock
Electrohydraulic actuator for valves with 20 mm lifting height. The actuator does not have quick shutdown in case of power failure. If it is desired, add SKD62 (RSK 5353628)
- Article number: 5353638
- Suppl. article no: BPZ:SKD60
- Ean no: 7612914018526
- Material class PEF21A
Technical data
- Operating time: 30 s
- Supply voltage: Other
- Degree of protection (IP): IP54
- Width: 127 mm
- Ambient temperature: -15-50 °C
- Depth: 169 mm
- Height: 300 mm
- Deactivated when closed: No
- Transmission: Hydraulic
- Control signal: 0 - 10 V
- Self-adjusting travel length: No
- Adjusting force: 1000 N
- Model: Linear
- Allowable relative humidity: 5-95 %
- Stroke length: 20 mm
- Suitable for valve: Yes
- Return at zero supply voltage: No
- Adjustable operating range: No
- Adjustable position feedback signal: No
- Regulation type modulating: Yes
- Connection to stop valve: Brand-dependent
- Suitable for air accessory: No
- Regulation type on/off: No
- Regulation type splitrange: No
- Position reporting system: 0 - 10 V
- Suitable for manual operation: Yes
- Housing material: Other
- Automatic stroke recognition: Yes
- Max. electric power input: 10 VA
- With mechanical setting indicator: Yes
- With safety function: No
- Auxiliary contacts: No
- Auxiliary contacts optional: Yes
- Energy consumption in operation: 8 W
- With top flange direct mount according to ISO 5211: No
- End contacts: None
- Explosion-proof: No
- Principle of operation safety function: NO Normaly open
- Potential free switch contact: No
- Running time: 30/15 sec
- Type: SKD60
