Eaton
Miniature circuit breaker PLSM 3-pole type C 10kA (3 BE)
MCB), 32A, 3P, TYPE C PLSM-C32/3
Article number: Suppl. article no:
2141632
Y7-242477
to see price and stock
Switch capacity: 10kA/400V in accordance with EN 60 898, 15kA/400V empty 40A in accordance with IEC 947-2
Energy limiting class 3
1 structural unit (BE)=17.5mm
Energy limiting class 3
1 structural unit (BE)=17.5mm
- Article number: 2141632
- Suppl. article no: Y7-242477
- Ean no: 4015082424770
- Material class QL4700
Technical data
- Packagin Size: 1 ST/40 ST
- Type: PLSM-C32/3
- Rated current: 32 A
- Number of poles (total): 3
- Width in number of modular spacings: 3
- Release characteristic: C
- Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V: 10 kA
- Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V: 0 kA
- Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V: 0 kA
- Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: 10 kA
- Rated voltage: 400 V
- Voltage type: AC
- Number of protected poles: 3
- Degree of protection (IP): IP20
- Frequency: 50-60 Hz
- Concurrently switching neutral conductor: No
- Current limiting class: 3
- Additional equipment possible: Yes
- Overvoltage category: 3
- Pollution degree: 2
- Connectable conductor cross section solid-core: 1-25 mm²
- Connectable conductor cross section multi-wired: 1-25 mm²
- Rated impulse withstand voltage Uimp: 4 kV
- Rated insulation voltage Ui: 440 V
- Ambient temperature during operating: -25-75 °C
- Explosion-proof: No
- Flush-mounted installation: No
- Built-in depth: 70.5 mm
- REACH Date: 2023-08-31
- REACH contains candidate substances: Bly
- REACH Information obligation: Yes
