Exxact switch surface-mounted, quick connection
SWITCH 1-POLE/2-WAY SCREWLESS WDE015521
Article number: Suppl. article no:
1820253
WDE015521
to see price and stock
Switch with quick connection for surface installation with integrated base plate. 16AX, 250V and with 2 neutral switching terminals. Inputs for cables from the back through outlets in the base plate or from all sides using cut-outs in the cover. The product is IP20 (even with the cover removed). IP21 when the cable is inserted from below. Possibility of further screw fastening of the lid. Can easily be equipped with impulse spring
- Article number: 1820253
- Suppl. article no: WDE015521
- Ean no: 3606489504113
- Material class QH1601
Technical data
- Packagin Size: 1 ST/5 ST
- Product series: Exxact
- Wiring system: Two-way switch
- Method of operation: Rocker/button
- Number of rockers: 1
- Lighting: No
- Push button switch: No
- Colour: White
- Label space/information surface: No
- Rated current: 16 A
- Switching current for fluorescent lamps: 16 AX
- RAL-number (similar): 9003
- Suitable for degree of protection (IP): IP20
- Material: Plastic
- Material quality: Thermoplastic
- Halogen free: Yes
- Mounting method: Surface mounted
- Device width: 65 mm
- Device height: 75 mm
- Device depth: 27 mm
- Built-in depth: 0 mm
- Assembly arrangement: Basic element with complete housing
- Nominal voltage: 250 V
- Washing machine switch: No
- Type of fastening: Other
- Surface finishing: Glossy
- Surface protection: Untreated
- Feedback-signal contact: No
- With mounting plate: Yes
- Connection type: Push-in clamp
- REACH Date: 2022-07-20
- REACH Information obligation: No
