Lamp socket ceiling DCL RS, Elko

CEILING OUTLET DCL PW EKO07330

Article number:

1885150

Suppl. article no:

EKO07330

‌
‌
‌

‌
‌

to see price and stock

DCL means Device for Connection of Luminaires, and is a plug and socket system for connecting the fixed lighting equipment. DCL roof sockets fit all ELKO roof boxes and mounting hooks for loads up to 15 kg. If the roof box is shallower than 40 mm, separate elevation frame E18 952 43 are used.
Quick Connect. Mounting depth 31 mm, Max load on roof hook 15 kg.

Article number:
1885150
Copy to clipboard
Suppl. article no:
EKO07330
Copy to clipboard
Ean no:
7020160733009
Copy to clipboard
Material class
QH5200
Copy to clipboard

Technical data

Packagin Size: 1 PCS/5 PCS/5 PCS/50 PCS
Colour: White
Number of units: 1
Number of socket outlets switchable: 1
Device width: 115 mm
Device height: 115 mm
Device depth: 40 mm
Nominal current: 6 A
Nominal voltage: 230 V
RAL-number (similar): 9003
With built-in USB power supply: No
Connection type: Push-in clamp
Surface finishing: Glossy
Mounting method: Flush-mounted
Transparent: No
Surface protection: Untreated
Suitable for degree of protection (IP): IP20
Type of fastening: Mounting with screw
Material: Plastic
Material quality: Thermoplastic
Halogen free: Yes
With on/off switch: No
Insulated mounting: No
With loop through function: Yes
Fault current protection: No
Frequency: 50 Hz
Eject-mechanism: No
Lockable: No
With miniature fuse: No
With function lighting: No
With enhanced contact protection: No
With hinged lid: No
With orientation lighting: No
Label space/information surface: No
Rotated central insert: No
Special power supply: No special power supply
Number of modules (module system): 0
For heavy conditions according to VDE: No
Overvoltage protection: No
Product series: RS
REACH Date: 2022-08-09
REACH Information obligation: No
