Nexa
Built-in dimmer ZBD-110 Z-wave, Nexa
Z-Wave Dimmer, Energymeasuring
Article number: Suppl. article no:
1711683
86826
to see price and stock
Universal dimmer for fixed installation with input for spring-loaded switches. Copes with the most common lamp types on the market. Automatically calibrates for leading or trailing edge control and minimum dimmer level. The receiver also measures how much connected load consumes and reports this to your controller, for example Nexa Bridge X.
- Article number: 1711683
- Suppl. article no: 86826
- Ean no: 7330545868265
- Material class QG7010
Technical data
- Packagin Size: 1 PCS/10 PCS/40 PCS
- Model: Dimming actuator
- Voltage: 100-240 V
- Number of outputs: 1
- Output power: 4-400 W
- Bus system KNX: No
- Bus system KNX-RF (Radio Frequency): No
- Bus system radio frequency: Yes
- Bus system LON: No
- Bus system Powernet: No
- Other bus systems: Other
- Radio frequency bidirectional: Yes
- With bus connection: Yes
- Bus module detachable: No
- Substation input: No
- Local operation/hand operation: No
- With LED indication: Yes
- Power boost suitable: No
- Parallel-service possible: No
- Frequency: 50-60 Hz
- Degree of protection (IP): IP00
- Mounting method: Built-in installation
- Type of load: Universal and LED Retrofit
- Max. switching power LED: 200 W
- REACH Date: 2022-02-01
- Compatible with Casambi: No
- REACH Information obligation: No
