Uni Loose Tube 9/125 Dca, Eurolan

UNILT 4X9/125 DCA T500 39UD-S1-04-02YL-500

Article number:

4704045

Suppl. article no:

39UD-S1-04-02YL-500

Normally in stock

to view the store status of the store

to see price and stock

Eurolan Uni LT fiber cables are used in backbone, distribution networks or in FTTH solutions. Can be laid indoors as it is or outdoors in pipes. Loosetube: ø 2.8 mm gel filled loose tube with 2 - 12 fibers; ø 3.5 mm loose tube with 24 fibers.
Temp operation: -30 ° C— +60 ° C
Sheath: 1 mm LSZH

Article number:
4704045
Copy to clipboard
Suppl. article no:
39UD-S1-04-02YL-500
Copy to clipboard
Ean no:
7333089012422
Copy to clipboard
Material class
QR1650
Copy to clipboard

Technical data

Packagin Size: 500 M
Type: 39UD-S1-04-02YL-500
Number of fibres: 4
Number of fibres per tube: 4
Outer diameter approximate: 7 mm
Colour outer sheath: Yellow
Fibre type: Single mode 9/125
Category: OS2
Blow in: No
Reaction-to-fire according to EN 13501-6: Flaming droplets/particles: d2
Reaction-to-fire according to EN 13501-6: Smoke production: s2
Reaction-to-fire according to EN 13501-6: Class: Dca
Specification material outer sheath: Polyethylene (PE)
Type of tube: Loose tube
Material outer sheath: Other
Suitable for underground installation: No
Armouring/reinforcement: Lap-screen
Material armouring: Other
Min. permitted bending radius, stationary application/permanent installation: 105 mm
With strain relief: Yes
Cable metal free: Yes
Longitudinal water blocking cable: Yes
Radial water blocking cable: Yes
With rodent protection: Yes
Oil resistant according to EN IEC 60811-404: No
Reaction-to-fire according to EN 13501-6: Acidity: a1
UV resistant: No
Resistant to chemicals: No
Cable geometry: Round
Max. tensile strength during installation: 1.8 kN
Weight: 57 kg/km
Cable width approximate: 7 mm
Cable height approximate: 7 mm
Flame retardant according to IEC 60332-1-2: Yes
Halogen free according to EN IEC 60754-1: Yes
Halogen free according to EN IEC 60754-2: Yes
Low smoke according to EN IEC 61034-2: Yes
REACH Date: 2023-02-20
REACH Information obligation: No
