Rubber cable TITANEX (H07RN-F) 450 / 750V, Nexans
TITANEX H07RN-F 4G6 20071698-901-00
Article number: Suppl. article no:
0547730
20071698-901-00
to see price and stock
TITANEX® H07RN-F 450/750 V is an oil and grease resistant flexible cable that can withstand sharp temperature changes and has great resistance to moisture and frost. It is intended for temporary installations indoors and outdoors. The cable can also be laid in ground with protection ( Suitable for connecting machines and other equipment that requires flexible cable.
EPR-insulated and rubber-sheathed connection cable with round multi-wire copper conductors. The cable is designed according to SS 424 02 35-4. The conductor has resistance according to SS EN 60228 class 5. The parts are color marked according to SS 424 17 20. The jacket is complementary. Lineax complies with CPR class E.
EPR-insulated and rubber-sheathed connection cable with round multi-wire copper conductors. The cable is designed according to SS 424 02 35-4. The conductor has resistance according to SS EN 60228 class 5. The parts are color marked according to SS 424 17 20. The jacket is complementary. Lineax complies with CPR class E.
- Article number: 0547730
- Suppl. article no: 20071698-901-00
- Ean no: 7330000130265
- Material class QA860A
Technical data
- Cable type: TITANEX H07RN-F
- Nominal cross section conductor: 6 mm²
- Dimension conductor x area: 4G6 mm²
- Outer diameter approx.: 17 mm
- Colour outer sheath: Black
- With protective conductor: Yes
- Nominal voltage U: 750 V
- Nominal voltage U0: 450 V
- Reaction-to-fire according to EN 13501-6: Class: Eca
- Conductor category: Class 5 = flexible
- Shape of conductor: Round
- Conductor material: Copper
- Conductor surface: Bare
- Permitted cable outer temperature during assembling/handling: -25-60 °C
- Oil resistant according to EN IEC 60811-404: Yes
- Permitted cable outer temperature after assembling without vibration: -40-90 °C
- Number of cores: 4
- Weight: 468 kg/km
- Reaction-to-fire according to EN 13501-6: Flaming droplets/particles: None
- Screen over stranding element: None
- Screen over stranding: None
- Low temperature resistant according to EN 60811-504+505+506: Yes
- Material outer sheath: Rubber
- Min. permitted bending radius, moving application/free movement: 102 mm
- Min. permitted bending radius, stationary application/permanent installation: 68 mm
- Core identification: Colour
- Reaction-to-fire according to EN 13501-6: Smoke production: None
- Specification core insulation: Rubber - ethylene propylene rubber (EPR)
- Specification material outer sheath: Rubber - ethylene propylene rubber (EPR)
- Suspension element: None
- Reaction-to-fire according to EN 13501-6: Acidity: None
- Torsion resistant: No
- Material core insulation: Other
- Cable geometry: Round
- Conductor resistance at 20 °C: 3.3 Ohm/km
- Core identification according to HD 308 S2: Yes
- Halogen free according to EN IEC 60754-2: No
- REACH Date: 2021-06-14
- REACH Information obligation: No
