Timer relay Kappa 7-function multi relay for 11-pin base
MULTIFUNCTION T-REALY 11-PIN 73129
Article number: Suppl. article no:
4074118
73129
to see price and stock
• Multi-function timing relay with 7 functions.
• Wide input voltage range 12-240 VAC/VDC
• 35 mm width
• 2 alternating contacts
K3ZM20 is a timing relay of standard design with seven functions and an input voltage range from 12 to 240V AC/DC. Connection of operating voltage is always done on the same connector, so the risk of incorrect connection is minimised.
Functions: (E) Turn-on delayed, (R) Shutoff delayed, (Ws) Turn-on by signal, (Wa) Shutoff by signal,(Es) Turn-on with control contact, (Wu) Pulse shortener, (Bp) Blink function.
• Wide input voltage range 12-240 VAC/VDC
• 35 mm width
• 2 alternating contacts
K3ZM20 is a timing relay of standard design with seven functions and an input voltage range from 12 to 240V AC/DC. Connection of operating voltage is always done on the same connector, so the risk of incorrect connection is minimised.
Functions: (E) Turn-on delayed, (R) Shutoff delayed, (Ws) Turn-on by signal, (Wa) Shutoff by signal,(Es) Turn-on with control contact, (Wu) Pulse shortener, (Bp) Blink function.
- Article number: 4074118
- Suppl. article no: 73129
- Ean no: 9008662005914
- Material class QP470B
Technical data
- Type: K3ZM20
- Rated control supply voltage DC: 12-240 V
- Rated control supply voltage AC 50 Hz: 12-240 V
- Voltage type for actuating: AC/DC
- Time range: 0.05-360000
- Information: Power consumption: 6VA (2W)
Frequency: AC 48 to 63 Hz Hz
