Ultrasonic sensor XX cylinder shape

D18 U SONIC SENSOR 500MM XX518A3PAM12

Article number:

3849628

Suppl. article no:

XX518A3PAM12

Normally in stock

to view the store status of the store

to see price and stock

Detection of any object or material.
Technical specifications:
Control voltage 12...24VDC (10...28V)
IP class 67
Load current 100 MA with overload and short-circuit protection
Temperature range:
Form F: -20...+65ºC

Article number:
3849628
Copy to clipboard
Suppl. article no:
XX518A3PAM12
Copy to clipboard
Ean no:
3389110974645
Copy to clipboard
Material class
QP033B
Copy to clipboard

Technical data

Packagin Size: 1 ST/15 ST/15 ST
Type: XX518A3PAM12
Adjustable distance: 51-508 mm
Type of analogy output: Other
Measuring range length: 51-508 mm
Diameter sensor: 18 mm
Voltage type: AC/DC
Type of electric connection: Connector M12
Width sensor: 18 mm
Setting procedure: Teach-In
Height of sensor: 18 mm
Housing material: Plastic
Length of sensor: 77.6 mm
Standard for interfaces: Other
Max. output current: 100 mA
Blind zone: 51 mm
Type of switch function: Normally open contact (NO)
Type of switching output: PNP/PNP
Explosion safety category for dust: None
Explosion safety category for gas: None
Construction type housing: Cylinder, screw-thread
Material active area of sensor: Plastic
No-load current: 40 mA
Material of cable sheath: Other
Relative linearity deflection: 0 %
AWG-number: 0
Ambient temperature: -20-65 °C
Supply voltage: 12-24 V
Relative repeat accuracy: 1.27 %
Switching frequency: 40 Hz
Synchronisation possible: No
Degree of protection (IP): IP67
REACH Date: 2022-07-20
REACH contains candidate substances: Bly | Boroxid, Diboron trioxide
REACH Information obligation: Yes
