Photo cell Osiris Compact 50 x 50 Universal Osiconcept

PES COMPACT UNI PROG 10-36 XUK0AKSAM12
Article number:
3847027
Suppl. article no:
XUK0AKSAM12
Normally in stock
 to view the store status of the store
 to see price and stock
Denna produkt innehåller ett eller flera ämnen på kandidatförteckningen.
All detection methods are available with a single product. The first multi-application photocell that handles all five detection systems (direct/direct with mixing away background , reflex, polarised reflex, one-way detection). A simple push of the button and the photo-electric cell is automatically configured and offers optimal performance for each application. This unique system is called Osi concept. For one-way detection it must also include a transmitter.
  • Article number:
    3847027
  • Suppl. article no:
    XUK0AKSAM12
  • Ean no:
    3389110160406
  • Material class
    QP302B
Technical data
  • Packagin Size: 1 ST/44 ST/88 ST
  • Type: XUK0AKSAM12
  • Max. switching distance: 30000 mm
  • Rated switching distance: 30000 mm
  • Type of electric connection: Connector M12
  • Type of switching output: PNP/NPN
  • Type of switch function: Programmable/configurable
  • Analogue output -10 V ... +10 V: No
  • Analogue output 0 V ... 10 V: No
  • Analogue output 0 mA ... 20 mA: No
  • Analogue output 4 mA ... 20 mA: No
  • Number of semiconductor outputs with signalling function: 1
  • Number of contact energized outputs with signalling function: 0
  • Number of protected semiconductor outputs: 1
  • Number of protected contact energized outputs: 0
  • Setting procedure: Teach-In
  • Housing material: Plastic
  • Construction type housing: Cuboid
  • Suitable for safety functions: No
  • Material of optical surface: Plastic
  • Max. output current: 100 mA
  • Max. output current at protected output: 100 mA
  • With other analogue output: No
  • With communication interface AS-Interface: No
  • With restart blockage: No
  • With time function: No
  • Min. reflector distance: 5000 mm
  • Rated control supply voltage DC: 12-24 V
  • Ambient temperature: -25-55 °C
  • Switching frequency: 250 Hz
  • Response time: 2 ms
  • Width sensor: 18 mm
  • Height of sensor: 50 mm
  • Length of sensor: 50 mm
  • Degree of protection (IP): IP65
  • Type of light: Polarized red light
  • Type of safety according to IEC 61496-1: 1
  • Operation agent-safety class: Safety class 0
  • Explosion safety category for gas: None
  • Pre failure notice: No
  • With communication interface analogue: No
  • With communication interface CANOpen: No
  • With communication interface DeviceNet: No
  • With communication interface Ethernet: No
  • With communication interface INTERBUS: No
  • With communication interface PROFIBUS: No
  • With communication interface RS-232: No
  • With communication interface RS-422: No
  • With communication interface RS-485: No
  • With communication interface SSD: No
  • With communication interface SSI: No
  • With monitoring function downstream switching devices: No
  • With reflector: No
  • Explosion safety category for dust: None
  • Sensing mode: Dark switching
  • Laser protection class: None
  • Voltage type: AC/DC
  • Type of interface for safety communication: Other
  • REACH Date: 2022-07-20
  • REACH contains candidate substances: Bly | 1,2-dimetoxietan, Dimethyl Glycol, 1,2-dimethoxyethane | 1,3-propanesultone 1,2-oxathiolane 2,2-dioxide
  • Information: System: Rated operating distance, Max / usable (m)
  • Scanning method: Transmitter/Receiver
  • REACH Information obligation: Yes
