Telemecanique
Limit switch XCKM for multi-directional movement (M20)
LIMIT SWITCH XCKM106H29
Article number: Suppl. article no:
3818253
XCKM106H29
to see price and stock
Protection class IP 66 (per IEC 529) metal design
PLEASE NOTE! With this actuator arm, the limit switch is not direct-opening.
PLEASE NOTE! With this actuator arm, the limit switch is not direct-opening.
- Article number: 3818253
- Suppl. article no: XCKM106H29
- Ean no: 3389110612240
- Material class QP040B
Technical data
- Packagin Size: 1 ST/18 ST
- Type: XCKM106H29
- Design: Spring-loaded pin
- Type of control element: Spring-rod
- Switching function: Quick-break switch
- Alignment of the control element: Other
- Housing material: Metal
- Type of electric connection: Cable entry metrical
- Degree of protection (IP): IP66/IP67
- Number of contacts as normally open contact: 1
- Number of safety auxiliary contacts: 0
- Number of contacts as change-over contact: 0
- Number of contacts as normally closed contact: 1
- Output electronic: No
- Explosion safety category for dust: None
- Explosion safety category for gas: None
- Coating housing: Other
- Construction type housing: Special construction
- Suitable for safety functions: No
- With status indication: No
- Rated operation current Ie at AC-15, 230 V: 3 A
- Ambient temperature during operating: -25-70 °C
- Width sensor: 63 mm
- Height of sensor: 64 mm
- Length of sensor: 30 mm
- Forced opening: Yes
- Type of interface: None
- Type of interface for safety communication: None
- Rated operation current Ie at DC-13, 230 V: 0.27 A
- Switching function latching: No
- REACH Date: 2022-07-20
- REACH contains candidate substances: Bly | 1,2-dimetoxietan, Dimethyl Glycol, 1,2-dimethoxyethane
- Cable entry: 3×M 20
- REACH Information obligation: Yes
- Contact function: 1 NO + 1 NC
