Limit switch ZCD/ZCP Osiconcept, separate parts

METAL BODY 1NO1NC SA ZCD21

Article number:

3818161

Suppl. article no:

ZCD21

‌
‌
‌

‌
‌

to see price and stock

Contact housing in metal or plastic design 30 x 30 x 73 mm.
Enclosure class IP66/67
Positive breaking contacts.
Contact specs: AC15 at Ue 240V = 3A, DC13 at Ue 250V = 0, 27A
Snap-in mounting for control head.
Cable inputs for contact housing ZCD (metal) and ZCP (plastic). (Applies to item nos. 3818215-3818214).

Article number:
3818161
Copy to clipboard
Suppl. article no:
ZCD21
Copy to clipboard
Ean no:
3389110185300
Copy to clipboard
Material class
QP040B
Copy to clipboard

Technical data

Packagin Size: 1 ST/40 ST
Type: ZCD21
Design: Separate cable input
Type of control element: None
Switching function: Quick-break switch
Alignment of the control element: Other
Housing material: Metal
Type of electric connection: Other
Degree of protection (IP): IP66/IP67
Number of contacts as normally open contact: 1
Number of safety auxiliary contacts: 0
Number of contacts as change-over contact: 0
Number of contacts as normally closed contact: 1
Output electronic: No
Explosion safety category for dust: None
Explosion safety category for gas: Other
Coating housing: Other
Construction type housing: Cuboid
Suitable for safety functions: No
With status indication: No
Rated operation current Ie at AC-15, 230 V: 1.5 A
Ambient temperature during operating: -25-70 °C
Width sensor: 31 mm
Height of sensor: 65 mm
Length of sensor: 30 mm
Forced opening: Yes
Type of interface: None
Type of interface for safety communication: None
Rated operation current Ie at DC-13, 230 V: 0.1 A
Switching function latching: No
REACH Date: 2022-07-20
REACH contains candidate substances: Bly | 1,2-dimetoxietan, Dimethyl Glycol, 1,2-dimethoxyethane
Material: Metal
REACH Information obligation: Yes
