Eaton
Mini contactor DIL EM, DC power supply with built-in extinguishing diode, power consumption 2.6 W
CONTACTORS DILEM-G 10213
Article number: Suppl. article no:
3250221
Y7-10213
to see price and stock
For mounting on 35 mm rail, alternatively, screw mounting. Additional block can be mounted without tools. Protection class IP 20, main dimensions BxHxDj: 45x58x52 mm. Thermal rated current AC 1: 20 A, motor rated current AC 3: 8.5 A/400 V 3 main contacts. Overcurrent relay ZE (32 535 00-18) mounted directly on the contactor.
- Article number: 3250221
- Suppl. article no: Y7-10213
- Ean no: 4015080102137
- Material class QO320B
Technical data
- Packagin Size: 1 ST/5 ST
- Type: DIL EM-10-G
- Rated operation power at AC-3, 400 V: 4 kW
- Rated operation current Ie at AC-1, 400 V: 22 A
- Rated operation current Ie at AC-3, 400 V: 9 A
- Rated control supply voltage AC 50 Hz: 0 V
- Rated control supply voltage DC: 24 V
- Number of normally open contacts as main contact: 3
- Number of normally closed contacts as main contact: 0
- Voltage type for actuating: DC
- Number of auxiliary contacts as normally open contact: 1
- Number of auxiliary contacts as normally closed contact: 0
- Type of electrical connection of main circuit: Screw connection
- Suitable for distribution board: No
- Rated operation current Ie at AC-4, 400 V: 6.6 A
- Rated operation power at AC-4, 400 V: 3 kW
- Rated operation power NEMA: 3.7 kW
- Rated control supply voltage AC 60 Hz: 0 V
- REACH Date: 2023-08-31
- REACH contains candidate substances: Bly
- Number of contacts: 1 + 0
- Auxiliary contacts: 1 + 0
- REACH Information obligation: Yes
