Schneider Electric
Mini contactor LC1K AC operated
CONTACTOR LC1K0901M7TQ
Article number: Suppl. article no:
3230171
LC1K0901M7TQ
to see price and stock
To shop with us, you need a registered company and a customer number.
3 or 4 main poles
- Article number: 3230171
- Suppl. article no: LC1K0901M7TQ
- Ean no: 3389110489873
- Material class QO360B
Technical data
- Packagin Size: 1 FRP/24 FRP/24 FRP
- Type: LC1K0901M7TQ
- Rated operation power at AC-3, 400 V: 4 kW
- Rated operation current Ie at AC-1, 400 V: 20 A
- Rated operation current Ie at AC-3, 400 V: 9 A
- Rated control supply voltage AC 50 Hz: 220-230 V
- Rated control supply voltage DC: 0 V
- Number of normally open contacts as main contact: 3
- Number of normally closed contacts as main contact: 0
- Voltage type for actuating: AC
- Number of auxiliary contacts as normally open contact: 0
- Number of auxiliary contacts as normally closed contact: 1
- Type of electrical connection of main circuit: Screw connection
- Modular version: No
- Rated operation current Ie at AC-4, 400 V: 6 A
- Rated operation power at AC-4, 400 V: 2.2 kW
- Rated control supply voltage AC 60 Hz: 220-230 V
- REACH Date: 2022-07-20
- REACH Information obligation: No
